W24S horizontal profile bending machine

 Introduction to W24S horizontal profile bending machine

Pronjas company’s W24S horizontal profile bending machine is an efficient and reliable profile processing equipment, which is specially used for bending all kinds of profiled steel, including angle steel, channel steel, I-beam, flat steel, square steel and round steel. With its advanced design and excellent performance, this machine can achieve high-precision profile bending and meet the needs of a wide range of industrial applications. W24S  bending machine not only has powerful functions, but also is easy to operate, which is suitable for the needs of various factories and manufacturing industries, especially in petroleum, chemical industry, hydropower, shipbuilding and machinery manufacturing industries.

Advantages

The design features of W24S  machine make it have obvious advantages in dealing with the profile. Its main advantages include:

1. Pre-bending function of profile: The W24S horizontal profile bending mahcine’s pre-bending function would make it possible to effectually decrease the waste before bending, to optimize material usage and reduce processing cost.
2. Correcting guide roller device: Guide roller device, suitable especially for rolling asymmetric profiles, without the materials being distorted in the bending process; it ensures the quality of finished products.
3. PLC control system: Integrated PLC control system enables automatic operation with improved efficiency of production, more suitable for mass production.
4. Mobile console: The machine is provided with a mobile console due to which it is easy for the workers to handle and, in turn, work efficiency is improved.

These advantages indeed make the W24S horizontal profile bending machine more competitive and offer users flexible processing options and efficient production schemes.

Product Benefits of W24S horizontal profile bending machine

Users who use W24S  machine will experience many benefits:

1. Cost saving: The pre-bending function and efficient processing can even lift up material waste, and therefore realize reduced production costs.
2. Improve production efficiency: PLC Automatic control systems have improved the work efficiency of the production line, especially for parts that need to be very accurate and have to be processed over and over again.
3. Improve product quality: The straightening guide roller device assures the profile does not twist during bending; therefore, it improves the general quality and appearance of the product.
4. Operation flexibility: The design of the mobile console improves the work position flexibility of the operator by allowing them to conveniently adjust working positions according to production requirements.

W24S Horizontal Profile Bending Machine Technical Parameter
Model		6	16	30	45	75	100	140	180	260	320	400	500
Max sector module of Elasticity(cm3)		6	16	30	45	75	100	140	180	260	320	400	500
Rolling Speed (m/min)		6	6	6	6	5	5	5	4	4	4	4	4
Profile Yield Limit (Mpa)		245	245	245	245	245	245	245	245	245	245	245	245
	Max section of Angle Bending	40×5	70×8	80×8	90×10	100×10	120×12	140×16	150×16	160×16	180×14	200×18	200×20
	Min bending dia.	800	1000	1200	1500	2000	2400	2500	2600	2600	3600	3600	4000
	Max section of Angle Bending	50×5	80×8	90×10	100×10	120×12	140×16	150×16	160×16	180×14	200×18	200×24	250×25
	Min bending dia.	800	1000	1100	1300	1600	1800	2200	2000	2500	3600	3600	4000
	Max section of C-channel Bending	8#	12#	16#	20#	25#	28#	30#	32#	36#	40#	45#	50#
	Min bending dia.	600	800	800	1000	1100	1700	1200	1500	1800	2000	2000	2400
	Max section of C-channel Bending	8#	12#	16#	20#	25#	28#	30#	32#	36#	40#	45#	50#
	Min bending dia.	700	900	1000	1150	1600	1700	1700	1800	1800	2000	2000	2000
	Max section of Bending Flat Bar	100×18	150×25	180×25	200×30	220×40	250×40	280×50	300×50	330×50	360×60	400×75	500×76
	Min bending dia.	600	700	800	900	1000	1200	1300	1500	1900	2000	2400	2400
	Max section of Bending Flat Bar	50×12	75×16	90×20	100×25	110×40	120×40	150×40	180×30	190×40	190×50	200×50	200×60
	Min bending dia.	500	760	800	1000	1100	1300	1500	2000	2000	2400	2200	2500
	Max section of Bending Pipe	42×4	76×4.5	89×5	89×8	114×5	159×5	168×6	168×8	219×8	245×8	273×8	323×10
	Min bending dia.	500	750	900	900	1200	2000	2000	2000	3500	3000	3500	4200
	Max section of Bending Round Steel	38	52	62	75	85	90	100	110	120	135	150	160
	Min bending dia.	450	600	600	800	1000	1100	1200	1300	1350	1800	2000	2000
	Max section of Bending Square	45×3	60×4	70×4	80×6	90×8	100×10	125×10	140×10	150×10	165×10	180×12	200×12
	Min bending dia	750	900	1000	1200	1600	2000	2500	3000	3000	3500	3500	5000
	Max section	/	/	/	/	10#	12.6#	14#	16#	18#	20.6#	22.6#	25.6#
	Min bending dia	/	/	/	/	2000	2500	3000	3500	4000	5000	8000	10000

Application

W24S horizontal profile bending machine is widely used in many industries, including but not limited to:

1. Petroleum Industry: used to manufacture structural parts such as pipelines and supports.
2. Chemical Industry: Suitable for processing all kinds of chemical equipment and accessories to improve the engineering applicability of equipment.
3. Hydropower Project: It is often used in the production of dams, pipelines and related accessories.
4. Shipbuilding: The production of hull and frame members has enhanced the structural strength and durability of ships.
5.  Mechanical Manufacturing: used to make important profiles of mechanical equipment, which improves the performance and stability of the equipment.

With its excellent performance and wide application, W24S horizontal profile bending machine has become the preferred equipment for many industry users.

Operation instruction

The operation of using W24S horizontal profile bending machine is relatively simple, and the following are the basic steps:

1. Preparation: According to different profile requirements, select the appropriate mold and install it on the equipment.
2. Setting parameters: Set parameters through the PLC interface to ensure that the machine meets the production requirements.
3. Baiting: Put the profile to be processed into the equipment to ensure its correct position.
4. Start machining: Start the machine, observe its operation and monitor the production status in real time to ensure the smooth machining process.
5. Inspection of finished products: After processing, check the quality and size of finished products to ensure that they meet the design standards.

For more detailed information and operation skills, please visit the related topic articles on our website.

Customer evaluation

Most customers are happy with the W24S horizontal profile bending machine. Some typical comments from users are as follows:

“The pre-bending function of this machine saves our materials to a great extent, and therefore the production cost goes down significantly.”

“PLC control system is easy and efficient, more useful in large-scale production.”

“The machining accuracy of W24S is very satisfactory to us, because quality has seen an appreciable improvement in finished products.”
